Revolve
Magnetic Strirrer
SKU RV-MS-15
Request a Quote
Pricing on request
Product information
Details & specifications
Details and specifications
This magnetic stirrer is a slim & compact electromagnetic stirrer designed with modern magnetic coil technology. It provides high IP protection class (IP 65) without any moving parts attached to it. Setting of speed and time is simple and easy with a digital display. For better mixing, pulse mode is provided in which a stirring bar can rotate clockwise & counter clockwise for every 30 seconds. This magnetic stirrer is designed for use in laboratories, pharmacies & schools for mixing liquids industry for mixing liquids.
Product identity
- SKU
- RV-MS-15
- Brand
- Revolve
- Category
- Benchtop Equipment
Specifications
- Stirring Quantity Max. Per Stirring Position (H2O)
- 800ml
- Number of Stirring Position
- 1
- Speed Range
- 15 - 1500RPM
- Time Range
- 1 to 99 minute & infinite mode
- Auto Direction Change/Pulse Mode
- Yes
- Auto Direction Change Time Interval
- 30seconds
- Digital Display
- Yes
- Recommended Bar Length
- 25mm
- Set-up Plate Material
- Stainless Steel
- Set-up Plate Dimensions
- Ø94mm
- Dimensions (L x W x H)
- 191 x 124 x 16.5mm
- Protection Class According to DIN EN 60529
- IP 65
- Permissible Ambient Temperature
- 5 - 40°C
- Weight
- 0.4 - 0.5Kg
- Permissible Relative Humidity
- ≤80%
- Power Adapter Detail
- Input: 100-240VAC, 50/60Hz Output: 9V ⎓ 1A
- Power Consumption
- 5W
- Altitude
- Use upto an altitude of 2000 m above MSL
- Pollution Degree
- 2
- Environment
- For indoor use only
