Revolve
Mini Vortex Mixer
SKU RV-VM-45F
Request a Quote
Pricing on request
Product information
Details & specifications
Details and specifications
This Mini Vortex Mixer is available in two variants: Fixed Speed and Variable Speed. It comes with a powerful brushless DC motor and delivers speed up to 4500 RPM. With an orbital motion of 4.5 mm it provides thorough mixing and it can accommodate plastic tubes & vials up to a 30 mm diameter. It is used in laboratories for the general mixing of applications in individual test tubes, up to a 30 mm diameter.
Product identity
- SKU
- RV-VM-45F
- Brand
- Revolve
- Category
- Benchtop Equipment
Specifications
- Motor Type
- BLDC
- Type of movement
- Orbital
- Shaker diameter
- 4.5mm
- Tube diameter
- Up to 30 mm
- Maximum Speed
- 2000 - 4500RPM
- Speed Accuracy
- ± 5 %
- Operation Type
- Touch
- Protection class according to DIN EN 60529
- IP 43
- Permissible ambient temperature
- 5 - 40°C
- Weight
- 0.55Kg
- Permissible relative moisture
- <80%
- Noise Level
- <50dB
- Dimensions (L x W x H)
- 100 x 100 x 70mm
- Input Voltage
- 9V ⎓ 1.2A
- Power Consumption
- 11W
