DISOL PRO Bottle Top Dispenser for Hydrofluoric Acid

SKU RV-BTD-HF

Available configurations

Request a Quote

Pricing on request

Browse more in Liquid Handling

Product information

Details & specifications

Details and specifications

DISOL PRO Bottle Top Dispenser (BTD) is a high precision liquid handling instrument engineered with carefully selected and tested materials for use with Hydrofluoric Acid (HF). DISOL PRO can precisely dispense high-purity media. When high-purity materials are dispensed with the dispenser after appropriate cleaning, they release virtually no metal ions. Built by our in-house team of product design engineers, it uses Springless Valve, an award winning technology, and Recirculation Valve for preventing loss of reagent during purging. DISOL PRO also features two product innovations, EasyKnob and FlexiNozzle that enhance its ease of use and flexibility. Designed with ergonomics and intuitive handling in mind, it exhibits excellent chemical compatibility with HYDROFLUORIC ACID (HF) and other reagents and chemicals to achieve precision and safety with reliability in practical laboratory environments.

Product identity

SKU
RV-BTD-HF
Brand
Revolve
Category
Liquid Handling

Specifications

Autoclaving Parameters
121°C and 15 psi for a duration of 10-15 minutes
Calibration Standard
ISO 8655 / ISO 17025
Adapter Sizes
28 mm, 32 mm, 38 mm, 40 mm and 45 mm
Valve System Material
High purity ceramic components
Piston Material
PTFE Piston with an ETP O-Ring
Adapter Rotation
360° rotation
Vol. Range
0.25-2.5ml
Increment
0.05ml
Accuracy ±%
0.5%
Accuracy ±ml
0.0125ml
CV ±%
0.2%
CV ±ml
0.005ml
