Digital Hotplate Stirrer Pro - 2200rpm, 550C, 20L capacity, ceramic top 180x180 mm
SKU RV-SH-550
Request a Quote
Pricing on request
Product information
Details & specifications
Details and specifications
This stirrer is specially designed for precise control of stirring speed and temperature which allows gentle to vigorous mixing with speed ranging from 200 to 2200 RPM with a maximum capacity of 20 Ltr. The multipurpose digital display assists users by displaying various parameters like actual & set temperature, speed, mode of operation, etc. The hotplate stirrer is suitable to use for mixing and/or heating the liquids with the maximum capacity of 20 Ltr. It is designed for use in general laboratories, pharmacies, schools and universities.
Product identity
- SKU
- RV-SH-550
- Brand
- Revolve
- Category
- Benchtop Equipment
Specifications
- Motor
- DC
- Number of stirring position
- 1
- Max Stirring quantity on Equip (H2O)
- 20Ltr
- Speed range
- 200 to 2200RPM
- Speed control
- 10 RPM / Step
- Temperature setting resolution
- 1°C / Step
- Time range
- 0 to 999 minutes & Infinite
- Heater Control Accuracy (+/-K)
- ±1.0°C
- Recommended Stirring bar length
- 25mm
- Set-up plate material
- Ceramic
- Set up plate dimensions
- 180 x 180mm
- Dimensions (L x W x H)
- 313 x 205 x 110mm
- Protection class
- IP 21
- Permissible ambient temp.
- 5-40°C
- Permissible relative humidity
- ≤80%
- Weight
- 4.9Kg
- Altitude
- Use upto an altitude of 2000 m above MSL
- Pollution Degree
- 2
- Environment
- For indoor use only
- Input Voltage
- 220-240V, 50Hz
- Motor rating Input & Output
- 5-7W
- Total Power Consumption
- 1,000W
- Safety Fuse Rating
- 5Amp
