Digital Hotplate Stirrer- 2200rpm, 320C, 10L capacity, ceramic coated SS top dia 140 mm
SKU RV-SH-320
Request a Quote
Pricing on request
Product information
Details & specifications
Details and specifications
This stirrer is specially designed for precise control of stirring speed and temperature which allows gentle to vigorous mixing with speed ranging from 200 to 2200 RPM with a maximum capacity of 10 Ltr. The multipurpose digital display assists users by displaying various parameters like actual & set temperature, speed, mode of operation, etc. The hotplate stirrer is suitable to use for mixing and/or heating the liquids with the maximum capacity of 10 Ltr. It is designed for use in general laboratories, pharmacies, schools and universities.
Product identity
- SKU
- RV-SH-320
- Brand
- Revolve
- Category
- Benchtop Equipment
Specifications
- Motor
- DC
- Number of stirring position
- 1
- Max Stirring Quantity on Equip (H2O)
- 10Liters
- Speed range
- 200 to 2200RPM
- Speed control
- 10 RPM / Step
- Heating Temp. range
- Room Temp. to 320°C
- Setting Temp.
- 5°C to 320°C
- Safe Temp
- 345
- Temperature control
- 1°C / Step
- Time range
- 1 to 999 minutes & Infinite
- Temp Accuracy (+/- K)
- 1
- Recommended Stirring bar length
- 25mm
- Set-up plate dimensions
- 140mm
- Dimensions (L x W x H)
- 248 x 156 x 104mm
- Heat output
- 600W
- Protection class according to DIN EN
- IP 21
- Permissible ambient temp.
- 5 - 40°C
- Permissible relative humidity
- 80%
- Weight
- 2Kg
- Input Voltage
- 110V / 220V, 60Hz / 50Hz
- Motor rating Input & Output
- 5-7W
- Total Power Consumption
- 620W
