Revolve
DATA LOGGER
SKU RV-DL-USB
Request a Quote
Pricing on request
Product information
Details & specifications
Details and specifications
The REVOLVE temperature humidity data logger is a reusable, LCD-equipped digital recorder designed for continuous monitoring. It supports configurable recording intervals, manual start/stop operation, onboard memory and USB 2.0 report retrieval in PDF and CSV formats.
Product identity
- SKU
- RV-DL-USB
- Brand
- Revolve
- Category
- Equipment
- Product type
- Equipment
Specifications
- Usage Type
- Reusable : With LCD display
- Temperature Sensor
- Digital sensors
- Measurement Range : Temperature
- -30 °C to +70 °C (-22 °F to +158 °F) ±0.5
- Temperature Accuracy
- ±0.5°C
- Resolution
- 0.1°C
- Memory Capacity
- Up to 24,000 temperature readings
- Recording Time
- Up to 160 days (default recording interval: 10 minutes)
- Startup Delay
- 30 minutes; user configurable
- Recording Interval
- 1 minute to 15 hours; user configurable
- Battery
- 3.6 V ER14250 lithium sub-battery; self-replaceable
- Display
- LCD screen
- Buttons
- START key (start/state), STOP key (stop/state)
- Startup Option
- Manual Button Start
- Alarm Indication
- Buzzer alarm prompt; bell icon shown on screen
- Report
- PDF + CSV; obtained via USB 2.0
- Dimensions / Weight
- 101 × 48 × 19 mm / 52 g
- Operating System
- Windows XP / 7 / 8 / 10 / 11 and Mac
- Environmental Rating
- IP54
Documentation
