Revolve
Automation Kjeldahl Distillation AKD50
SKU RV-AKD-50
Request a Quote
Pricing on request
Product information
Details & specifications
Details and specifications
The Revolve Automation Kjeldahl Distillation Unit is a unique solution for
quantifying nitrogen/protein content using the Kjeldahl method, featuring an
automated analyzer with premium performance that delivers the highest sample
throughput, increased boiler capacity, and is the most productive system available.
It complies with various official steam distillation methods for applications such as
determining ammoniacal nitrogen, protein content, nitrogen content (both direct
and indirect), nitric nitrogen (after reduction with Devarda’s Alloy), and alcohol
content.
Product identity
- SKU
- RV-AKD-50
- Brand
- Revolve
- Category
- Food Analysis
Specifications
- Steam addition
- Automatic
- Distilled water addition
- Automatic
- Alkali addition
- Automatic
- Acid addition
- Automatic
- Display
- 7” touch screen
- Tube capacity (ml)
- 250 ml / 400 ml
- Steam power (adjustable)
- 10 - 100%
- Maximum distillation time
- 20mins
- Reagent level sensor
- Yes
- Anytime alkali addition
- Yes
- Tube error detection
- Yes
- Door close sensor
- Yes
- One point calibration alkali and distilled water pump
- Yes
- Two point calibration for acid pump
- Yes
- Real time monitoring of process parameters
- Yes
- SELV protection
- Yes
- User editable programs
- No. of programme
- PC connectivity
- Yes
- Print readout
- Yes
- Auto Drain
- Yes
- N/P recovery
- >99.5%
- Nitrogen reproducibility
- ±1%
- RSD
- <1%
- LOD
- 1- 200 mg with of >0.1 mg of nitrogen 0.1% nitrogen & 0.2% protein
- Current consumption
- 10A
- Power consumption
- 1,500W
- Dimensions (L X B X H)
- 470 X 470 X 830mm
